FCW007-000048 D-SUB Cable DB9P MALE TO DB9P MALE L=630MM
-
EU RoHS
Compliant(2011/65/EU) -
EU REACH
Dose not contain REACH SVHC(1907/2006/EC) -
EU ELV
Compliant(2000/53/EC)
- Type
- TypeD-SUB Cable DB9P MALE TO DB9P MALE L=630MM
- Electrical
- Operating voltage300V
- Current - Maximum per Contact2.00A
- Temperature Range operating-15ºC~+105ºC
- Cable specification
- ConductorTin Plated Copper
- Cross section28AWG(0.08mm²)x9C
- JacketPolyvinyl chloride(PVC)
- StandardUL/2651
- Compatible Parts
- Pulg-
- Receptacle-
- Terminal-
- Assembly shell-
