FUS441 Micro USB AB-Type 5Circuits 90°Angle Female(SMT)
-
EU RoHS
Compliant(2011/65/EU) -
EU REACH
Dose not contain REACH SVHC(1907/2006/EC) -
EU ELV
Compliant(2000/53/EC)
- Category
- CategoryMicro USB AB-Type 5Circuits 90°Angle Female(SMT)
- Circuits5
- Electrical
- Current - Maximum per Contact1.80A
- Voltage - Maximum30V
- Contact Resistance30/50 mΩ Max
- Insulation Resistance100 MΩ Min
- Withstanding Voltage100V AC r.m.s
- Temperature Range operating-30ºC~+80ºC
- Material and Plating
- Material-MetalPhosphor Bronze
- Material - Plating MatingGold
- Material - Plating TerminationGold
- Material - ResinHight Temperature Thermoplastic UL94V-0
- Compatible Parts
- Pulg-
- Receptacle-
- Terminal-
- Assembly shell-
