JL27 ,插座 ,2位 ,直端 ,通孔焊接
F1JL27-S02SD000-01
JL27, Socket, 2Circuits, 180°Vertical, Through Hole
F1JL27-S02SD000-01 Copy
Share this product
Stock(pcs)
40
Lead time

≦ 40 In stock

＞ 40 Estimated delivery date 2026-01-03

MPQ
1
MOQ
10
Quantity Unit Price
1 $3.965433
10 $3.750676
50 $3.321163
100 $3.106407
500 $2.676894
1000 $2.147565
2500 $2.117317
5000 $2.087070
10000 $2.056823
25000 $2.026575

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Printed Circuit Connector
Product Category
JL27
Style
Socket
Pitch
3.96mm
Row Option
Single row
Number of Positions
2Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
13A
Voltage(Max)
250V
Contact Resistance
3.8 mΩ Max
Insulation Resistance
5000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-55ºC~+125ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Copper alloy
Plating
Gold plated
Plating Thickness
0.1μm
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
Tube

Product Drawings

FXJL27-SXXSD000-01

3D Drawings

F1JL27-S02SD000-01-REF
Plug
JL27, Plug, 2Circuits, 180°Vertical, Soldering

F0JL27-P02SW000-01

JL27, Plug, 2Circuits, 180°Vertical, Soldering

 JL27, One-way plug cable, 2Circuits, L=200mm

FWJL27-S02020WH-01

JL27, One-way plug cable, 2Circuits, L=200mm
