F1JL27-S16RD000-01
JL27 ,插座 ,16位 ,弯端 ,通孔焊接
JL27, Socket, 16Circuits, 90°Angle, Through Hole
Product Number：F1JL27-S16RD000-01
Production Status： Active
JL27, Socket, 16Circuits, 90°Angle, Through Hole
The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
Product Catalog
Connectors
Product System
Printed Circuit Connector
Product Category
JL27
Style
Socket
Pitch
3.96mm
Row Option
Single row
Number of Positions
16Circuits
Orientation
Right angle(90°)
Colour
Natural
Current(Max)
13A
Voltage(Max)
250V
Contact Resistance
3.8 mΩ Max
Insulation Resistance
5000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-55ºC~+125ºC
Mounting Style
Through hole
Material-Contact
Copper alloy
Plating
Gold plated
Plating Thickness
0.1μm
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Tube

Product Drawings

FXJL27-SXXRD000-01.pdf
Plug
JL27, Plug, 16Circuits, 180°Vertical, Soldering
F0JL27-P16SW000-01
JL27, Plug, 16Circuits, 180°Vertical, Soldering
