板对板连接器,0.5mm,母,20位,垂直(180度),表面贴装,0.025μm,(组合高度2.5mm),
FBB05001-F20S1013W5M
Board to Board Connector, 0.5mm, Female, 20Circuits, Vertical(180°), SMT, 0.025μm, (Mated height 2.5mm),
FBB05001-F20S1013W5M Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2026-01-01
MPQ
2000
MOQ
2000
Quantity Unit Price
1 $0.447881
10 $0.365196
50 $0.304559
100 $0.278376
500 $0.245301
1000 $0.190866
5000 $0.188110
10000 $0.185354

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Board to Board Connector
Style
Socket
Gender
Female
Pitch
0.5mm
Row Option
Dual row
Number of Positions
20Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
0.5A
Voltage(Max)
50V
Contact Resistance
40 mΩ Max
Insulation Resistance
500 MΩ Min
Withstanding Voltage
250V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
SMT
Durability (Mating Cycles Max.)
30
Material
Material-Contact
Phosphor bronze
Plating
Gold plated
Plating Thickness
0.025μm
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FBB05001-F-1.pdf

3D Drawings

FBB05001-F20S1XX3W5M_REF
Plug
Board to Board 180°Vertical 0.5mm 20Circuits (Mated height 2.5mm)

FBB05001-M20S1013W5M

Board to Board 180°Vertical 0.5mm 20Circuits (Mated height 2.5mm)
