简牛 2.54mm 90°插件 20位
FBH25402-D20B1001K6K
Box Header 2.54mm 90°Angle 20Circuits(DIP)
FBH25402-D20B1001K6K Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-10-16
MPQ
20
MOQ
20
Quantity Unit Price
1 $0.214069
10 $0.201369
50 $0.175970
100 $0.163270
500 $0.137871
1000 $0.102439
2500 $0.101035
5000 $0.099632
10000 $0.098229
25000 $0.096826

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Box Header/IDC
Product Category
Box Header
Style
Socket
Pitch
2.54mm
Row Option
Dual row
Number of Positions
20Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
3A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
500V AC r.m.s
Operating Temperature Range
-40ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Gold plated
Plating Thickness
Gold flash
Material-Resin
PBT
Flammability Rating
UL94 V-0
Packaging
Packaging
Tray

Product Drawings

FBH25402.pdf

3D Drawings

FBH25402-D20B1XXXK6K_REF
