FBH25423-D10S1001K6B03

Box Header, 2.54mm, 10Circuits, Vertical(180°), Through hole, PBT

Product Number：FBH25423-D10S1001K6B03

Production Status： Active

Box Header, 2.54mm, 10Circuits, Vertical(180°), Through hole, PBT

The pictures are for reference only for installation methods, please refer to the specifications and drawings for details

Specification Indication

Quantity	Unit Price (including tax) Unit Price
1+	{{0.552744\|tradeCurrencySymbol({digits:6})}}
10+	{{0.479775\|tradeCurrencySymbol({digits:6})}}
50+	{{0.399508\|tradeCurrencySymbol({digits:6})}}
100+	{{0.37032\|tradeCurrencySymbol({digits:6})}}
500+	{{0.321066\|tradeCurrencySymbol({digits:6})}}

Stock(pcs) 0

Lead time {{product.leadDate|timezoneDate}}

MOQ 1000

MPQ 5000

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Product Catalog

Connectors

Product System

Box Header/IDC

Product Category

Box Header

Style

Socket

Pitch

2.54mm

Row Option

Dual row

Number of Positions

10Circuits

Orientation

Vertical(180°)

Colour

Black

Current(Max)

Voltage(Max)

250V

Contact Resistance

20 mΩ Max

Insulation Resistance

1000 MΩ Min

Withstanding Voltage

500V AC r.m.s

Operating Temperature Range

-40ºC~+85ºC

Mounting Style

Through hole

Material-Contact

Brass

Plating

Gold plated

Plating Thickness

Gold flash

Material-Resin

PBT

Flammability Rating

UL94 V-0

Packaging

PE Bag

Product Drawings

FBH25423_Series.pdf

REACH (EU REACH Regulation)	Does not contain REACH SVHC (1907/2006/EC)
ROHS (EU ROHS Directive)	Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2)
ELV (EU ELV Directive)	Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements
