线端插头胶壳 1.25mm 3位
FHG12502-S03M2W1B
Wire to board housing 1.25mm 3Circuits
FHG12502-S03M2W1B Copy
Share this product
Stock(pcs)
67
Lead time

≦ 67 In stock

＞ 67 Estimated delivery date 2025-10-14

MPQ
2000
MOQ
2000
Quantity Unit Price
1 $0.014703
10 $0.013708
50 $0.011717
100 $0.010722
500 $0.008731
1000 $0.005207
2500 $0.005136
5000 $0.005065
10000 $0.004994
25000 $0.004924

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Housing
Gender
Male
Pitch
1.25mm
Row Option
Single row
Number of Positions
3Circuits
Orientation
Vertical(180°)
Colour
White
Electrical
Current(Max)
1A
Voltage(Max)
125V
Operating Temperature Range
-25ºC~+85ºC
Material
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FHG12502.pdf

3D Drawings

FHG12502-S03M2W1B-REF
Terminal
Wire to board terminal 1.25mm Female(Tin-Plated)

FT12501-F2H

Wire to board terminal 1.25mm Female(Tin-Plated)
Plug
Wire to board housing 1.25mm 3Circuits

FHG12508-S03F2W1B

Wire to board housing 1.25mm 3Circuits
Receptacle
Wafer 1.25mm 90°Angle 3Circuits (SMT)

FWF12504-S03B24W5M

Wafer 1.25mm 90°Angle 3Circuits (SMT)

 Wafer 1.25mm 180°Vertical 3Circuits (SMT)

FWF12505-S03S24W5M

Wafer 1.25mm 180°Vertical 3Circuits (SMT)

 Wafer 1.25mm 180°Vertical 3Circuits (DIP)

FWF12506-S03S24W5B

Wafer 1.25mm 180°Vertical 3Circuits (DIP)

 Wafer 1.25mm 90°Angle 3Circuits (DIP)

FWF12507-S03B24W5B

Wafer 1.25mm 90°Angle 3Circuits (DIP)
