线端插头胶壳 1.25mm 5位
FHG12502-S05M2W1B
Wire to board housing 1.25mm 5Circuits
FHG12502-S05M2W1B Copy
Share this product
Stock(pcs)
1940
Lead time

≦ 1940 In stock

＞ 1940 Estimated delivery date 2025-12-29

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.023412
10 $0.021827
50 $0.018657
100 $0.017072
500 $0.013903
1000 $0.008291
2500 $0.008178
5000 $0.008065
10000 $0.007952
25000 $0.007840

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Housing
Gender
Male
Pitch
1.25mm
Row Option
Single row
Number of Positions
5Circuits
Orientation
Vertical(180°)
Colour
White
Electrical
Current(Max)
1A
Voltage(Max)
125V
Operating Temperature Range
-25ºC~+85ºC
Material
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FHG12502.pdf
Terminal
Wire to board terminal 1.25mm Female(Tin-Plated)

FT12501-F2H

Wire to board terminal 1.25mm Female(Tin-Plated)
Plug
Wire to board housing 1.25mm 5Circuits

FHG12508-S05F2W1B

Wire to board housing 1.25mm 5Circuits
Receptacle
Wafer 1.25mm 90°Angle 5Circuits (SMT)

FWF12504-S05B24W5M

Wafer 1.25mm 90°Angle 5Circuits (SMT)

 Wafer 1.25mm 180°Vertical 5Circuits (SMT)

FWF12505-S05S24W5M

Wafer 1.25mm 180°Vertical 5Circuits (SMT)

 Wafer 1.25mm 180°Vertical 5Circuits (DIP)

FWF12506-S05S24W5B

Wafer 1.25mm 180°Vertical 5Circuits (DIP)

 Wafer 1.25mm 90°Angle 5Circuits (DIP)

FWF12507-S05B24W5B

Wafer 1.25mm 90°Angle 5Circuits (DIP)
