排针,2.54mm,双塑 双排,16位,垂直(180度),表面贴装,0.025μm,PA6T
FPH25473-D16S1014150501M
Pin Header, 2.54mm, Dual row, 16Circuits, Vertical(180°), SMT, 0.025μm, PA6T
FPH25473-D16S1014150501M Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-08-15
MPQ
20
MOQ
20
Quantity Unit Price
1 $0.389800
10 $0.337826
50 $0.280656
100 $0.255968
500 $0.224784
1000 $0.175410
5000 $0.172811
10000 $0.165123
Category
Product Catalog
Connectors
Product System
Pin Header/Female Header
Product Category
Pin Header
Style
Plug
Pitch
2.54mm
Row Option
Dual row
Number of Positions
16Circuits
Peg
Without peg
Orientation
Vertical(180°)
Colour
Black
Electrical
Current(Max)
3A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
600V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Brass
Plating
Gold plated
Plating Thickness
0.025μm
Material-Resin
PA6T
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FPH25473 Series

3D Drawings

FPH25473-D16S1014150501M-REF
