板装插座 0.80mm ,4位 ,立贴 ,镀金 ,LCP
FWF08001-S04S13W5M
Wafer 0.80mm, 4Circuits, 180° Vertical(SMT), Gold, LCP
FWF08001-S04S13W5M Copy
Share this product
Stock(pcs)
3521
Lead time

≦ 3521 In stock

＞ 3521 Estimated delivery date 2025-10-13

MPQ
2000
MOQ
2000
Quantity Unit Price
1 $0.276242
10 $0.184161
50 $0.157853
100 $0.144698
500 $0.122336
1000 $0.089121
5000 $0.087806
10000 $0.086490

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
0.8mm
Row Option
Single row
Number of Positions
4Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
0.5A
Voltage(Max)
30V
Contact Resistance
20 mΩ Max
Insulation Resistance
100 MΩ Min
Withstanding Voltage
200V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Phosphor bronze
Plating
Gold plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FWF08001 Series

Product Specifications

FWF08001Productspecification.pdf
Plug
Wire to board housing 0.8mm, 4Circuits, PA46

FHG08002-S04M6W5B

Wire to board housing 0.8mm, 4Circuits, PA46
