板装插座 1.25mm 插件 180° 2位 (46)
FWF12506-S02S24W5B
Wafer 1.25mm 180°Vertical 2Circuits (DIP)(HF)
FWF12506-S02S24W5B Copy
Share this product
Stock(pcs)
990
Lead time

≦ 990 In stock

＞ 990 Estimated delivery date 2025-10-14

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.022627
10 $0.021095
50 $0.018032
100 $0.016500
500 $0.013437
1000 $0.008013
2500 $0.007904
5000 $0.007795
10000 $0.007686
25000 $0.007577

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
1.25mm
Row Option
Single row
Number of Positions
2Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
1A
Voltage(Max)
125V
Contact Resistance
20 mΩ Max
Insulation Resistance
100 MΩ Min
Withstanding Voltage
250V AC r.m.s
Operating Temperature Range
-40ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Phosphor bronze
Plating
Bright tin plated
Material-Resin
PA46
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF12506series.pdf

Product Specifications

FWF12506Productspecification.pdf
Plug
Wire to board housing 1.25mm 2Circuits

FHG12502-S02M2W1B

Wire to board housing 1.25mm 2Circuits
