板装插座 1.25mm 插件 180° 15位 (46)
FWF12506-S15S24W5B
Wafer 1.25mm 180°Vertical 15Circuits (DIP)
FWF12506-S15S24W5B Copy
Share this product
Stock(pcs)
865
Lead time

≦ 865 In stock

＞ 865 Estimated delivery date 2025-06-05

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.130655
10 $0.122273
50 $0.105511
100 $0.097129
500 $0.080367
1000 $0.053154
2500 $0.052429
5000 $0.051703
10000 $0.050977
25000 $0.050252
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
1.25mm
Row Option
Single row
Number of Positions
15Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
1A
Voltage(Max)
125V
Contact Resistance
20 mΩ Max
Insulation Resistance
100 MΩ Min
Withstanding Voltage
250V AC r.m.s
Operating Temperature Range
-40ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Phosphor bronze
Plating
Bright tin plated
Material-Resin
PA46
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF12506series.pdf

Product Specifications

FWF12506Productspecification.pdf
Plug
Wire to board housing 1.25mm 15Circuits

FHG12502-S15M2W1B

Wire to board housing 1.25mm 15Circuits
