板装插座 1.5mm 立贴 9位 (9T)
FWF15005-S09S24W5M
Wafer 1.5mm 180°Vertical 9Circuits (SMT)
FWF15005-S09S24W5M Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-08-15
MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.235291
10 $0.188780
50 $0.161420
100 $0.153213
500 $0.125853
1000 $0.090833
5000 $0.088644
10000 $0.087550
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
1.5mm
Row Option
Single row
Number of Positions
9Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
1A
Voltage(Max)
50V
Contact Resistance
20 mΩ Max
Insulation Resistance
500 MΩ Min
Withstanding Voltage
500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA9T
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FWF15005 series

Product Specifications

FWF15005Productspecification.pdf
Plug
Wire to board housing 1.50mm 9Circuits

FHG15001-S09M2W1B

Wire to board housing 1.50mm 9Circuits
