板装插座 2mm ,3位 ,立贴
FWF20023-S03S23W5M
Wafer 2mm, 3Circuits, 180° Vertical(SMT)
FWF20023-S03S23W5M Copy
Share this product
Stock(pcs)
543
Lead time

≦ 543 In stock

＞ 543 Estimated delivery date 2025-12-30

MPQ
800
MOQ
800
Quantity Unit Price
1 $0.132661
10 $0.124791
50 $0.109051
100 $0.101181
500 $0.085441
1000 $0.063483
2500 $0.062613
5000 $0.061743
10000 $0.060874
25000 $0.060004

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
2mm
Row Option
Single row
Number of Positions
3Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
2A
Voltage(Max)
125V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
800V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FWF20023_Series

3D Drawings

FWF20023-S03S23W5M_REF

Product Specifications

FWF20023Productspecification.pdf
Plug
Wire to board housing 2mm 3Circuits

FHG20005-S03M2W1B

Wire to board housing 2mm 3Circuits
