板装插座 2.5mm 插件 180° 9位(圆针)
FWF25003-S09S22W5B
Wafer 2.5mm 180°Vertical 9Circuits (DIP)
FWF25003-S09S22W5B Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-05-30
MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.079693
10 $0.074298
50 $0.063508
100 $0.058114
500 $0.047324
1000 $0.028222
2500 $0.027838
5000 $0.027454
10000 $0.027070
25000 $0.026686
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
2.5mm
Row Option
Single row
Number of Positions
9Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
3A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1000V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF25003 Series
Plug
Wire to board housing 2.5mm 9Circuits

FHG25002-S09M2W1B

Wire to board housing 2.5mm 9Circuits
