板装插座 2.5mm 插件 90° 3位(圆针)
FWF25004-S03B22W5B
Wafer 2.5mm 90°Angle 3Circuits (DIP)
FWF25004-S03B22W5B Copy
Share this product
Stock(pcs)
5
Lead time

≦ 5 In stock

＞ 5 Estimated delivery date 2025-05-30

MPQ
1000
MOQ
50000
Quantity Unit Price
1 $0.041276
10 $0.038482
50 $0.032894
100 $0.030100
500 $0.024511
1000 $0.014617
2500 $0.014418
5000 $0.014219
10000 $0.014021
25000 $0.013822
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
2.5mm
Row Option
Single row
Number of Positions
3Circuits
Orientation
Right angle(90°)
Colour
Natural
Electrical
Current(Max)
3A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1000V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF25004 series
Plug
Wire to board housing 2.5mm 3Circuits

FHG25002-S03M2W1B

Wire to board housing 2.5mm 3Circuits
