板装插座 2.5mm 插件 180° 7位(带锁扣)
FWF25012-S07S22W1B
Wafer 2.5mm 180°Vertical 7Circuits (DIP)
FWF25012-S07S22W1B Copy
Share this product
Stock(pcs)
70
Lead time

≦ 70 In stock

＞ 70 Estimated delivery date 2025-10-14

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.051099
10 $0.047640
50 $0.040722
100 $0.037263
500 $0.030344
1000 $0.018096
2500 $0.017850
5000 $0.017604
10000 $0.017357
25000 $0.017111

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
2.5mm
Row Option
Single row
Number of Positions
7Circuits
Orientation
Vertical(180°)
Colour
White
Electrical
Current(Max)
3A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1000V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF25012_Series

Product Specifications

FWF25012Productspecification.pdf
Plug
Wire to board housing 2.5mm 7Circuits

FHG25006-S07M2W1B

Wire to board housing 2.5mm 7Circuits
