板装插座 3mm 插件 180° 2位
FWF30001-D02S22K6B
Wafer 3mm 180°Vertical 2Circuits (DIP)
FWF30001-D02S22K6B Copy
Share this product
Stock(pcs)
242
Lead time

≦ 242 In stock

＞ 242 Estimated delivery date 2025-12-30

MPQ
1000
MOQ
2000
Quantity Unit Price
1 $0.144248
10 $0.135691
50 $0.118576
100 $0.110018
500 $0.092903
1000 $0.069027
2500 $0.068082
5000 $0.067136
10000 $0.066190
25000 $0.065245

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
2Circuits
Orientation
Vertical(180°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA9T
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF30001Series.pdf

Product Specifications

FWF30001Productspecification.pdf
Plug
Wire to board housing 3mm 2Circuits

FHG30001-D02M2K6B

Wire to board housing 3mm 2Circuits
