板装插座 3mm 插件 180° 8位
FWF30001-D08S22K6K
Wafer 3mm 180°Vertical 8Circuits (DIP)
FWF30001-D08S22K6K Copy
Share this product
Stock(pcs)
758
Lead time

≦ 758 In stock

＞ 758 Estimated delivery date 2026-01-04

MPQ
180
MOQ
1080
Quantity Unit Price
1 $0.251513
10 $0.236592
50 $0.206750
100 $0.191830
500 $0.161988
1000 $0.120357
2500 $0.118708
5000 $0.117060
10000 $0.115411
25000 $0.113762

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
8Circuits
Orientation
Vertical(180°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA9T
Flammability Rating
UL94 V-0
Packaging
Packaging
Tray

Product Drawings

FWF30001Series.pdf

3D Drawings

FWF30001-D08S22K6K_REF

Product Specifications

FWF30001Productspecification.pdf
Plug
Wire to board housing 3mm 8Circuits

FHG30001-D08M2K6B

Wire to board housing 3mm 8Circuits
