板装插座 3mm 插件 180° 10位
FWF30001-D10S22K6K
Wafer 3mm 180°Vertical 10Circuits (DIP)
FWF30001-D10S22K6K Copy
Share this product
Stock(pcs)
2014
Lead time

≦ 2014 In stock

＞ 2014 Estimated delivery date 2026-01-04

MPQ
150
MOQ
1050
Quantity Unit Price
1 $0.284882
10 $0.267981
50 $0.234180
100 $0.217279
500 $0.183478
1000 $0.136325
2500 $0.134457
5000 $0.132590
10000 $0.130722
25000 $0.128855

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
10Circuits
Orientation
Vertical(180°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA9T
Flammability Rating
UL94 V-0
Packaging
Packaging
Tray

Product Drawings

FWF30001Series.pdf

3D Drawings

FWF30001-D10S22K6K_REF

Product Specifications

FWF30001Productspecification.pdf
Plug
Wire to board housing 3mm 10Circuits

FHG30001-D10M2K6B

Wire to board housing 3mm 10Circuits
