板装插座 3mm 插件 90° 4位(带定位柱)
FWF30002-D04B22K6B
Wafer 3mm 90°Angle 4Circuits (DIP)
FWF30002-D04B22K6B Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-12-30
MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.131958
10 $0.124129
50 $0.108473
100 $0.100644
500 $0.084987
1000 $0.063146
2500 $0.062281
5000 $0.061416
10000 $0.060551
25000 $0.059686

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
4Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA9T
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF30002series

3D Drawings

FWF30002-D04_ref

Product Specifications

FWF30002Productspecification.pdf
Plug
Wire to board housing 3mm 4Circuits

FHG30001-D04M2K6B

Wire to board housing 3mm 4Circuits
