板装插座 3mm 插件 90° 12位(带定位柱)
FWF30002-D12B22K6B
Wafer 3mm 90°Angle 12Circuits (DIP)
FWF30002-D12B22K6B Copy
Share this product
Stock(pcs)
418
Lead time

≦ 418 In stock

＞ 418 Estimated delivery date 2025-12-30

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.278940
10 $0.262392
50 $0.229296
100 $0.212748
500 $0.179652
1000 $0.133482
2500 $0.131653
5000 $0.129825
10000 $0.127996
25000 $0.126168

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
12Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA9T
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF30002series

Product Specifications

FWF30002Productspecification.pdf
Plug
Wire to board housing 3mm 12Circuits

FHG30001-D12M2K6B

Wire to board housing 3mm 12Circuits
