板装插座 3mm 插件 90° 14位(带定位柱)
FWF30002-D14B22K6B
Wafer 3mm 90°Angle 14Circuits (DIP)
FWF30002-D14B22K6B Copy
Share this product
Stock(pcs)
1133
Lead time

≦ 1133 In stock

＞ 1133 Estimated delivery date 2025-12-30

MPQ
320
MOQ
960
Quantity Unit Price
1 $0.287936
10 $0.270854
50 $0.236691
100 $0.219609
500 $0.185446
1000 $0.137787
2500 $0.135899
5000 $0.134012
10000 $0.132124
25000 $0.130237

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
14Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA9T
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF30002series

3D Drawings

FWF30002-D14B22K6B_ref

Product Specifications

FWF30002Productspecification.pdf
Plug
Wire to board housing 3mm 14Circuits

FHG30001-D14M2K6B

Wire to board housing 3mm 14Circuits
