板装插座 3mm 插件 180° 5位
FWF30004-S05S22K6B
Wafer 3mm 180°Vertical 5Circuits (DIP)
FWF30004-S05S22K6B Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-12-30
MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.243794
10 $0.162529
50 $0.136315
100 $0.124781
500 $0.109052
1000 $0.075235
5000 $0.072614
10000 $0.070517

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Single row
Number of Positions
5Circuits
Orientation
Vertical(180°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA6T
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF30004 Series
Plug
Wire to board housing 3mm 5Circuits

FHG30002-S05M2K6B

Wire to board housing 3mm 5Circuits
