板装插座 3mm 插件 90° 2位
FWF30005-S02B22K6B
Wafer 3mm 90°Angle 2Circuits(DIP)
FWF30005-S02B22K6B Copy
Share this product
Stock(pcs)
581
Lead time

≦ 581 In stock

＞ 581 Estimated delivery date 2025-12-30

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.165638
10 $0.155812
50 $0.136159
100 $0.126332
500 $0.106679
1000 $0.079263
2500 $0.078177
5000 $0.077091
10000 $0.076006
25000 $0.074920

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Single row
Number of Positions
2Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PBT
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF30005

3D Drawings

FWF30005-S02B22K6B_REF
Plug
Wire to board housing 3mm 2Circuits

FHG30002-S02M2K6B

Wire to board housing 3mm 2Circuits
