板装插座 3mm 插件 90° 5位
FWF30005-S05B22K6B
Wafer 3mm 90°Angle 5Circuits(DIP)
FWF30005-S05B22K6B Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-12-30
MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.214463
10 $0.201740
50 $0.176294
100 $0.163571
500 $0.138125
1000 $0.102627
2500 $0.101222
5000 $0.099816
10000 $0.098410
25000 $0.097004

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Single row
Number of Positions
5Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PBT
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FWF30005
Plug
Wire to board housing 3mm 5Circuits

FHG30002-S05M2K6B

Wire to board housing 3mm 5Circuits
