板装插座 3mm 立贴 12位
FWF30016-D12S23K6M
Wafer 3mm 180°Vertical 12Circuits (SMT)
FWF30016-D12S23K6M Copy
Share this product
Stock(pcs)
286
Lead time

≦ 286 In stock

＞ 286 Estimated delivery date 2026-01-04

MPQ
300
MOQ
900
Quantity Unit Price
1 $0.678097
10 $0.568405
50 $0.498601
100 $0.458713
300 $0.378937
900 $0.279217
4500 $0.275228
9000 $0.271239

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
12Circuits
Orientation
Vertical(180°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1000V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Brass
Plating
Matte tin plated
Material-Resin
PA9T
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FWF30016 Series

3D Drawings

FWF30016-D12S23K6M_REF
Plug
Wire to board housing 3mm 12Circuits

FHG30001-D12M2K6B

Wire to board housing 3mm 12Circuits
