板装插座 3mm 卧贴 12位(带鱼叉)
FWF30019-D12B23K6M
Wafer 3mm 90°Angle 12Circuits (SMT)
FWF30019-D12B23K6M Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-12-30
MPQ
200
MOQ
1000
Quantity Unit Price
1 $1.009280
10 $0.867350
50 $0.756960
100 $0.693880
500 $0.567720
1000 $0.439983
5000 $0.433675
10000 $0.427367

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
12Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Brass
Plating
Matte tin plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FWF30019 Series
Plug
Wire to board housing 3mm 12Circuits

FHG30001-D12M2K6B

Wire to board housing 3mm 12Circuits

 Wire to board housing 3mm 12Circuits

FHG30006-D12M2BKB

Wire to board housing 3mm 12Circuits
