板装插座 3mm 卧贴 3位
FWF30020-S03B23K6M
Wafer 3mm 90°Angle 3Circuits (SMT)
FWF30020-S03B23K6M Copy
Share this product
Stock(pcs)
55
Lead time

≦ 55 In stock

＞ 55 Estimated delivery date 2025-12-30

MPQ
500
MOQ
1000
Quantity Unit Price
1 $0.343672
10 $0.324127
50 $0.285037
100 $0.265493
500 $0.226403
1000 $0.176631
2500 $0.174203
5000 $0.171775
10000 $0.169347
25000 $0.166919

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Single row
Number of Positions
3Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Brass
Plating
Matte tin plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FWF30020 Series

3D Drawings

FWF30020-S03B23K6M-REF
Plug
Wire to board housing 3mm 3Circuits

FHG30002-S03M2K6B

Wire to board housing 3mm 3Circuits
