板装插座 3mm 卧贴 4位
FWF30020-S04B23K6M
Wafer 3mm 90°Angle 4Circuits (SMT)
FWF30020-S04B23K6M Copy
Share this product
Stock(pcs)
398
Lead time

≦ 398 In stock

＞ 398 Estimated delivery date 2025-12-29

MPQ
500
MOQ
1000
Quantity Unit Price
1 $0.507390
10 $0.478535
50 $0.420824
100 $0.391968
500 $0.334257
1000 $0.260775
2500 $0.257190
5000 $0.253605
10000 $0.250021
25000 $0.246436

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Single row
Number of Positions
4Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Brass
Plating
Matte tin plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FWF30020 Series

3D Drawings

FWF30020-S04B23K6M_ref
Plug
Wire to board housing 3mm 4Circuits

FHG30002-S04M2K6B

Wire to board housing 3mm 4Circuits
