板装插座 3mm 卧贴 5位
FWF30020-S05B23K6M
Wafer 3mm 90°Angle 5Circuits (SMT)
FWF30020-S05B23K6M Copy
Share this product
Stock(pcs)
10
Lead time

≦ 10 In stock

＞ 10 Estimated delivery date 2025-12-30

MPQ
500
MOQ
1000
Quantity Unit Price
1 $0.504078
10 $0.475411
50 $0.418077
100 $0.389410
500 $0.332076
1000 $0.259072
2500 $0.255511
5000 $0.251950
10000 $0.248389
25000 $0.244828

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Single row
Number of Positions
5Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Brass
Plating
Matte tin plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FWF30020 Series
Plug
Wire to board housing 3mm 5Circuits

FHG30002-S05M2K6B

Wire to board housing 3mm 5Circuits
