板装插座 3mm 卧贴 22位 (大卡扣）
FWF30025-D22B23BKM
Wafer 3mm 90°Angle 22Circuits (SMT)
FWF30025-D22B23BKM Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-09-05
MPQ
200
MOQ
2000
Quantity Unit Price
1 $0.996497
10 $0.827599
50 $0.760040
100 $0.716127
500 $0.611410
1000 $0.461091
5000 $0.454335
10000 $0.447579
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
22Circuits
Orientation
Right angle(90°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Brass
Plating
Matte tin plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

销售图FWF30025-DXXB23BKM
Plug
Wire to board housing 3mm 22Circuits

FHG30006-D22M2BKB

Wire to board housing 3mm 22Circuits
