板装插座 3mm 插件 180° 10位 (大卡扣）
FWF30027-D10S23BKK-B
Wafer 3mm 180°Vertical 10Circuits (DIP)
FWF30027-D10S23BKK-B Copy
Share this product
Stock(pcs)
196
Lead time

≦ 196 In stock

＞ 196 Estimated delivery date 2026-01-04

MPQ
216
MOQ
1944
Quantity Unit Price
1 $0.448652
10 $0.423137
50 $0.372107
100 $0.346592
500 $0.295562
1000 $0.230586
2500 $0.227416
5000 $0.224247
10000 $0.221077
25000 $0.217908

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
10Circuits
Orientation
Vertical(180°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Matte tin plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Tray

Product Drawings

FWF30027-DXXS23BKX-B.pdf
Plug
Wire to board housing 3mm 10Circuits

FHG30006-D10M2BKB

Wire to board housing 3mm 10Circuits
