板装插座 3mm 插件 180° 20位 (大卡扣）
FWF30027-D20S23BKK-B
Wafer 3mm 180°Vertical 20Circuits (DIP)
FWF30027-D20S23BKK-B Copy
Share this product
Stock(pcs)
38
Lead time

≦ 38 In stock

＞ 38 Estimated delivery date 2026-01-04

MPQ
120
MOQ
2040
Quantity Unit Price
1 $0.705459
10 $0.666310
50 $0.588012
100 $0.548863
500 $0.470565
1000 $0.375934
2500 $0.370749
5000 $0.365563
10000 $0.360378
25000 $0.355193

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
20Circuits
Orientation
Vertical(180°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Matte tin plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Tray

Product Drawings

FWF30027-DXXS23BKX-B.pdf
Plug
Wire to board housing 3mm 20Circuits

FHG30006-D20M2BKB

Wire to board housing 3mm 20Circuits
