板装插座 3mm 插件 180° 24位 (大卡扣）
FWF30027-D24S23BKK-B
Wafer 3mm 180°Vertical 24Circuits (DIP)
FWF30027-D24S23BKK-B Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2026-01-04
MPQ
96
MOQ
2016
Quantity Unit Price
1 $1.123404
10 $1.061715
50 $0.938338
100 $0.876649
500 $0.753272
1000 $0.606395
2500 $0.598002
5000 $0.589609
10000 $0.581216
25000 $0.572822

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3mm
Row Option
Dual row
Number of Positions
24Circuits
Orientation
Vertical(180°)
Colour
Black
Electrical
Current(Max)
5A
Voltage(Max)
250V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Matte tin plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Tray

Product Drawings

FWF30027-DXXS23BKX-B.pdf
Plug
Wire to board housing 3mm 24Circuits

FHG30006-D24M2BKB

Wire to board housing 3mm 24Circuits
