板装插座 3.96mm 插件 180° 3位(6T)
FWF39601-S03S24W5B
Wafer 3.96mm 180°Vertical 3Circuits(DIP)
FWF39601-S03S24W5B Copy
Share this product
Stock(pcs)
15405
Lead time

≦ 15405 In stock

＞ 15405 Estimated delivery date 2025-12-29

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.102783
10 $0.080171
50 $0.075031
100 $0.071948
500 $0.061670
1000 $0.046047
5000 $0.045224
10000 $0.044813

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3.96mm
Row Option
Single row
Number of Positions
3Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
7A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA6T
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

Drawing-FWF39601

Product Specifications

FWF39601Productspecification.pdf
Plug
Wire to board housing 3.96mm 3Circuits

FHG39601-S03M2W1B

Wire to board housing 3.96mm 3Circuits
