板装插座 3.96mm 插件180° 12位
FWF39601-S12S22W1B
Wafer 3.96mm 180°Vertical 12Circuits (DIP)
FWF39601-S12S22W1B Copy
Share this product
Stock(pcs)
588
Lead time

≦ 588 In stock

＞ 588 Estimated delivery date 2025-12-29

MPQ
500
MOQ
1000
Quantity Unit Price
1 $0.231983
10 $0.183009
50 $0.157233
100 $0.149500
500 $0.123724
1000 $0.091247
5000 $0.089185
10000 $0.088154

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3.96mm
Row Option
Single row
Number of Positions
12Circuits
Orientation
Vertical(180°)
Colour
White
Electrical
Current(Max)
7A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

Drawing-FWF39601

Product Specifications

FWF39601Productspecification.pdf
Plug
Wire to board housing 3.96mm 12Circuits

FHG39601-S12M2W1B

Wire to board housing 3.96mm 12Circuits
