板装插座 3.96mm 卧贴 4位
FWF39615-S04B23W5M
Wafer 3.96mm 90°Angle 4Circuits (SMT)
FWF39615-S04B23W5M Copy
Share this product
Stock(pcs)
200
Lead time

≦ 200 In stock

＞ 200 Estimated delivery date 2025-06-25

MPQ
300
MOQ
300
Quantity Unit Price
1 $0.292589
10 $0.275231
50 $0.240515
100 $0.223157
500 $0.188442
1000 $0.140013
2500 $0.138095
5000 $0.136177
10000 $0.134259
25000 $0.132341
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3.96mm
Row Option
Single row
Number of Positions
4Circuits
Orientation
Right angle(90°)
Colour
Natural
Electrical
Current(Max)
7A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
LCP
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FWF39615 Series

3D Drawings

FWF39615-S04B23W5M_ref
Plug
Wire to board housing 3.96mm 4Circuits

FHG39601-S04M2W1B

Wire to board housing 3.96mm 4Circuits
