板装插座 4.2mm 插件 90° 12位(实心针)
FWF42003-D12B22TK
Wafer 4.2mm 90°Angle 12Circuits(DIP)
FWF42003-D12B22TK Copy
Share this product
Stock(pcs)
3342
Lead time

≦ 3342 In stock

＞ 3342 Estimated delivery date 2025-12-29

MPQ
200
MOQ
1000
Quantity Unit Price
1 $0.329321
10 $0.310592
50 $0.273135
100 $0.254406
500 $0.216949
1000 $0.169255
2500 $0.166929
5000 $0.164602
10000 $0.162276
25000 $0.159949

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
4.2mm
Row Option
Dual row
Number of Positions
12Circuits
Orientation
Right angle(90°)
Colour
Clear
Electrical
Current(Max)
9A
Voltage(Max)
250V
Contact Resistance
15 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-2
Packaging
Packaging
Tray

Product Drawings

FWF42003 series

Product Specifications

Product specification FWF42003
Plug
Wire to board housing 4.2mm 12Circuits

FHG42001-D12M2TB

Wire to board housing 4.2mm 12Circuits
