板装插座 4.2mm 插件 90° 2位(实心针)(带定位柱)
FWF42004-D02B22TK
Wafer 4.2mm 90°Angle 2Circuits (DIP)
FWF42004-D02B22TK Copy
Share this product
Stock(pcs)
4832
Lead time

≦ 4832 In stock

＞ 4832 Estimated delivery date 2025-12-29

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.144703
10 $0.136118
50 $0.118949
100 $0.110365
500 $0.093196
1000 $0.069245
2500 $0.068296
5000 $0.067348
10000 $0.066399
25000 $0.065451

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
4.2mm
Row Option
Dual row
Number of Positions
2Circuits
Orientation
Right angle(90°)
Colour
Clear
Electrical
Current(Max)
9A
Voltage(Max)
250V
Contact Resistance
15 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-2
Packaging
Packaging
Tray

Product Drawings

FWF42004 series

3D Drawings

FWF42004-D02B22TK-REF

Product Specifications

FWF42004Productspecification.pdf
Plug
Wire to board housing 4.2mm 2Circuits

FHG42001-D02M2TB

Wire to board housing 4.2mm 2Circuits
