板装插座 4.2mm 插件 90° 2位(实心针)
FWF42007-S02B22TK
Wafer4.2mm 90°Angle 2Circuits (DIP)
FWF42007-S02B22TK Copy
Share this product
Stock(pcs)
20
Lead time

≦ 20 In stock

＞ 20 Estimated delivery date 2025-10-13

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.146913
10 $0.138197
50 $0.120766
100 $0.112051
500 $0.094619
1000 $0.070302
2500 $0.069339
5000 $0.068376
10000 $0.067413
25000 $0.066450

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
4.2mm
Row Option
Single row
Number of Positions
2Circuits
Orientation
Right angle(90°)
Colour
Clear
Electrical
Current(Max)
9A
Voltage(Max)
250V
Contact Resistance
15 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-2
Packaging
Packaging
Tray

Product Drawings

FWF42007 series

3D Drawings

FWF42007-S02B22TK_REF

Product Specifications

FWF42007Productspecification.pdf
Plug
Wire to board housing 4.2mm 2Circuits

FHG42003-S02M2TB

Wire to board housing 4.2mm 2Circuits
