JL23 ,插座 ,8位 ,弯端 ,通孔焊接
F0JL23-S08RD000-01
JL23, Socket, 8Circuits, 90°Angle, Through Hole
F0JL23-S08RD000-01 Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-10-21
MPQ
1
MOQ
10
Quantity Unit Price
1 $4.888515
10 $4.625287
50 $4.098831
100 $3.835604
500 $3.309148
1000 $2.651079
2500 $2.613475
5000 $2.575871
10000 $2.538267
25000 $2.500663

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Printed Circuit Connector
Product Category
JL23
Style
Socket
Pitch
2.54mm
Row Option
Dual row
Number of Positions
8Circuits
Orientation
Right angle(90°)
Colour
Green
Electrical
Current(Max)
3A
Voltage(Max)
300V
Contact Resistance
10 mΩ Max
Insulation Resistance
5000 MΩ Min
Withstanding Voltage
1000V AC r.m.s
Operating Temperature Range
-55ºC~+125ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Copper alloy
Plating
Gold plated
Plating Thickness
0.1μm
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
Tube

Product Drawings

F0JL23-SXXRD000-01

3D Drawings

F0JL23-S08RD000-01_REF
Plug
JL23, Plug, 8Circuits, 180°Vertical, Soldering

F0JL23-P08SW000-01

JL23, Plug, 8Circuits, 180°Vertical, Soldering

 JL23, One-way plug cable, 8Circuits, L=110mm

FWJL23-S08011GN-01

JL23, One-way plug cable, 8Circuits, L=110mm
