JL23 ,插座 ,24位 ,直端 ,通孔焊接
F1JL23-S24SD000-01
JL23, Socket, 24Circuits, 180°Vertical, Through Hole
F1JL23-S24SD000-01 Copy
Share this product
Stock(pcs)
0
Lead time
Estimated delivery date 2025-10-21
MPQ
1
MOQ
10
Quantity Unit Price
1 $9.110609
10 $8.625850
50 $7.656333
100 $7.171575
500 $6.202058
1000 $4.954517
2500 $4.883229
5000 $4.811941
10000 $4.740653
25000 $4.669365

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Printed Circuit Connector
Product Category
JL23
Style
Socket
Pitch
2.54mm
Row Option
Dual row
Number of Positions
24Circuits
Orientation
Vertical(180°)
Colour
Green
Electrical
Current(Max)
3A
Voltage(Max)
300V
Contact Resistance
10 mΩ Max
Insulation Resistance
5000 MΩ Min
Withstanding Voltage
1000V AC r.m.s
Operating Temperature Range
-55ºC~+125ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Copper alloy
Plating
Gold plated
Plating Thickness
0.1μm
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
Tube

Product Drawings

FXJL23-SXXSD000-01
Plug
JL23, Plug, 24Circuits, 180°Vertical, Soldering

F0JL23-P24SW000-01

JL23, Plug, 24Circuits, 180°Vertical, Soldering

 JL23, One-way plug cable, 24Circuits, 0.2M

FWJL23-S24020WH-01

JL23, One-way plug cable, 24Circuits, 0.2M
