线端插头胶壳 1.25mm 7位
FHG12502-S07M2W1B
Wire to board housing 1.25mm 7Circuits
FHG12502-S07M2W1B Copy
Share this product
Stock(pcs)
323
Lead time

≦ 323 In stock

＞ 323 Estimated delivery date 2025-10-14

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.032228
10 $0.030046
50 $0.025683
100 $0.023501
500 $0.019138
1000 $0.011413
2500 $0.011258
5000 $0.011102
10000 $0.010947
25000 $0.010792

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Housing
Gender
Male
Pitch
1.25mm
Row Option
Single row
Number of Positions
7Circuits
Orientation
Vertical(180°)
Colour
White
Electrical
Current(Max)
1A
Voltage(Max)
125V
Operating Temperature Range
-25ºC~+85ºC
Material
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FHG12502.pdf

3D Drawings

FHG12502-S07M2W1B_REF
Terminal
Wire to board terminal 1.25mm Female(Tin-Plated)

FT12501-F2H

Wire to board terminal 1.25mm Female(Tin-Plated)
Receptacle
Wafer 1.25mm 90°Angle 7Circuits (SMT)

FWF12504-S07B24W5M

Wafer 1.25mm 90°Angle 7Circuits (SMT)

 Wafer 1.25mm 180°Vertical 7Circuits (SMT)

FWF12505-S07S24W5M

Wafer 1.25mm 180°Vertical 7Circuits (SMT)

 Wafer 1.25mm 180°Vertical 7Circuits (DIP)

FWF12506-S07S24W5B

Wafer 1.25mm 180°Vertical 7Circuits (DIP)

 Wafer 1.25mm 90°Angle 7Circuits (DIP)

FWF12507-S07B24W5B

Wafer 1.25mm 90°Angle 7Circuits (DIP)
