线端插头胶壳 1.25mm 9位
FHG12502-S09M2W1B
Wire to board housing 1.25mm 9Circuits
FHG12502-S09M2W1B Copy
Share this product
Stock(pcs)
947
Lead time

≦ 947 In stock

＞ 947 Estimated delivery date 2025-10-14

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.040849
10 $0.038084
50 $0.032554
100 $0.029788
500 $0.024258
1000 $0.014466
2500 $0.014269
5000 $0.014072
10000 $0.013876
25000 $0.013679

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Housing
Gender
Male
Pitch
1.25mm
Row Option
Single row
Number of Positions
9Circuits
Orientation
Vertical(180°)
Colour
White
Electrical
Current(Max)
1A
Voltage(Max)
125V
Operating Temperature Range
-25ºC~+85ºC
Material
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FHG12502.pdf
Terminal
Wire to board terminal 1.25mm Female(Tin-Plated)

FT12501-F2H

Wire to board terminal 1.25mm Female(Tin-Plated)
Receptacle
Wafer 1.25mm 90°Angle 9Circuits (SMT)

FWF12504-S09B24W5M

Wafer 1.25mm 90°Angle 9Circuits (SMT)

 Wafer 1.25mm 180°Vertical 9Circuits (SMT)

FWF12505-S09S24W5M

Wafer 1.25mm 180°Vertical 9Circuits (SMT)

 Wafer 1.25mm 180°Vertical 9Circuits (DIP)

FWF12506-S09S24W5B

Wafer 1.25mm 180°Vertical 9Circuits (DIP)

 Wafer 1.25mm 90°Angle 9Circuits (DIP)

FWF12507-S09B24W5B

Wafer 1.25mm 90°Angle 9Circuits (DIP)
