线端插头胶壳 1.25mm 14位
FHG12502-S14M2W1B
Wire to board housing 1.25mm 14Circuits
FHG12502-S14M2W1B Copy
Share this product
Stock(pcs)
27
Lead time

≦ 27 In stock

＞ 27 Estimated delivery date 2025-10-14

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.062054
10 $0.057853
50 $0.049452
100 $0.045251
500 $0.036850
1000 $0.021975
2500 $0.021676
5000 $0.021377
10000 $0.021078
25000 $0.020779

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Housing
Gender
Male
Pitch
1.25mm
Row Option
Single row
Number of Positions
14Circuits
Orientation
Vertical(180°)
Colour
White
Electrical
Current(Max)
1A
Voltage(Max)
125V
Operating Temperature Range
-25ºC~+85ºC
Material
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FHG12502.pdf

3D Drawings

FHG12502-S14M2W1B_REF
Terminal
Wire to board terminal 1.25mm Female(Tin-Plated)

FT12501-F2H

Wire to board terminal 1.25mm Female(Tin-Plated)
Receptacle
Wafer 1.25mm 90°Angle 14Circuits (SMT)

FWF12504-S14B24W5M

Wafer 1.25mm 90°Angle 14Circuits (SMT)

 Wafer 1.25mm 180°Vertical 14Circuits (SMT)

FWF12505-S14S24W5M

Wafer 1.25mm 180°Vertical 14Circuits (SMT)

 Wafer 1.25mm 180°Vertical 14Circuits (DIP)

FWF12506-S14S24W5B

Wafer 1.25mm 180°Vertical 14Circuits (DIP)

 Wafer 1.25mm 90°Angle 14Circuits (DIP)

FWF12507-S14B24W5B

Wafer 1.25mm 90°Angle 14Circuits (DIP)
