板装插座 1.25mm 卧贴 4位 (9T)
FWF12504-S04B24W5M
Wafer 1.25mm 90°Angle 4Circuits (SMT)
FWF12504-S04B24W5M Copy
Share this product
Stock(pcs)
6516
Lead time

≦ 6516 In stock

＞ 6516 Estimated delivery date 2025-06-05

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.185755
10 $0.083971
50 $0.069976
100 $0.061070
500 $0.055981
1000 $0.034606
5000 $0.034098
10000 $0.033589
Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
1.25mm
Row Option
Single row
Number of Positions
4Circuits
Orientation
Right angle(90°)
Colour
Natural
Electrical
Current(Max)
1A
Voltage(Max)
125V
Contact Resistance
20 mΩ Max
Insulation Resistance
100 MΩ Min
Withstanding Voltage
250V AC r.m.s
Operating Temperature Range
-40ºC~+85ºC
Mechanical
Mounting Style
SMT
Material
Material-Contact
Phosphor bronze
Plating
Bright tin plated
Material-Resin
PA9T
Flammability Rating
UL94 V-0
Packaging
Packaging
Reel

Product Drawings

FWF12504 series

3D Drawings

FWF12504-4P_ref

Product Specifications

FWF12504Productspecification.pdf
Plug
Wire to board housing 1.25mm 4Circuits

FHG12502-S04M2W1B

Wire to board housing 1.25mm 4Circuits
Receptacle
Wafer 1.25mm, 4Circuits, 180° Vertical(SMT), PA9T

FWF12520-S04S23NAM

Wafer 1.25mm, 4Circuits, 180° Vertical(SMT), PA9T
