板装插座 3.96mm 插件180° 7位
FWF39601-S07S22W1B
Wafer 3.96mm 180°Vertical 7Circuits (DIP)
FWF39601-S07S22W1B Copy
Share this product
Stock(pcs)
4025
Lead time

≦ 4025 In stock

＞ 4025 Estimated delivery date 2025-12-26

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.157551
10 $0.126726
50 $0.107888
100 $0.102751
500 $0.085626
1000 $0.061308
5000 $0.059938
10000 $0.059253

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3.96mm
Row Option
Single row
Number of Positions
7Circuits
Orientation
Vertical(180°)
Colour
White
Electrical
Current(Max)
7A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

Drawing-FWF39601

Product Specifications

FWF39601Productspecification.pdf
Plug
Wire to board housing 3.96mm 7Circuits

FHG39601-S07M2W1B

Wire to board housing 3.96mm 7Circuits
