线端插头胶壳 3.96mm 7位(带锁扣)
FHG39601-S07M2W1B
Wire to board housing 3.96mm 7Circuits
FHG39601-S07M2W1B Copy
Share this product
Stock(pcs)
1273
Lead time

≦ 1273 In stock

＞ 1273 Estimated delivery date 2025-12-29

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.068807
10 $0.064149
50 $0.054833
100 $0.050175
500 $0.040860
1000 $0.024367
2500 $0.024035
5000 $0.023704
10000 $0.023372
25000 $0.023040

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Housing
Gender
Male
Pitch
3.96mm
Row Option
Single row
Number of Positions
7Circuits
Orientation
Vertical(180°)
Colour
White
Electrical
Current(Max)
7A
Voltage(Max)
250V
Operating Temperature Range
-25ºC~+85ºC
Material
Material-Resin
PA66
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

FHG39601 Series
Terminal
Wire to board terminal 3.96mm Female(Tin-Plated)

FT39601-F2H

Wire to board terminal 3.96mm Female(Tin-Plated)
Receptacle
Wafer 3.96mm 180°Vertical 7Circuits (DIP)

FWF39601-S07S22W1B

Wafer 3.96mm 180°Vertical 7Circuits (DIP)

 Wafer 3.96mm 180°Vertical 7Circuits (DIP) (Canceled No.2Circuits)

FWF39601-S07S22W1B-E2

Wafer 3.96mm 180°Vertical 7Circuits (DIP) (Canceled No.2Circuits)

 Wafer 3.96mm 180°Vertical 7Circuits (DIP) (Canceled No.2, 4, 6Circuits)

FWF39601-S07S22W1B-E246

Wafer 3.96mm 180°Vertical 7Circuits (DIP) (Canceled No.2, 4, 6Circuits)

 Wafer 3.96mm 180°Vertical 7Circuits (DIP) (Canceled No. 6 Circuits)

FWF39601-S07S22W1B-E6

Wafer 3.96mm 180°Vertical 7Circuits (DIP) (Canceled No. 6 Circuits)

 Wafer 3.96mm 180°Vertical 7Circuits(DIP)

FWF39601-S07S24W5B

Wafer 3.96mm 180°Vertical 7Circuits(DIP)

 Wafer 3.96mm 90°Angle 7Circuits (DIP)(HF)

FWF39602-S07B22W1B

Wafer 3.96mm 90°Angle 7Circuits (DIP)(HF)

 Wafer 3.96mm 180°Vertical 7Circuits (SMT)

FWF39614-S07S25W5M

Wafer 3.96mm 180°Vertical 7Circuits (SMT)
